4.3. Disarming
Once ELIOS 3 has landed on the ground or is safely held by an operator, you must stop the motors. To do so,
disarm the drone with the following input:
1. Left and right stick down and to the center
Figure 4.3: Disarming sequence
THE AIRCRAFT CAN ALSO BE DISARMED IN MID-AIR, RESULTING IN A FREE-FALL. IF
PERFORMED AT MORE THAN 1M (3.3 FEET) ABOVE GROUND THIS WILL SERIOUSLY
DAMAGE THE AIRCRAFT.
4.4. Aircraft controls
ELIOS 3 orientation and flight direction are defined in relation to its inner-frame.
