9.6. Changing an LED:
REQUIRED TOOLS (YOU WILL FIND ALL THOSE TOOLS WITHIN THE PROVIDED TOOLBOX):
1. Torx T6 screwdriver.
LED PANELS MUST BE REPLACED ONE BY ONE, NEVER REMOVE
SEVERAL PANELS AT THE SAME TIME.
Here is the step-by-step procedure on how to change an LED panel:
● Remove the top and bottom screw of the panel you need to replace.
● Remove the panel by pulling it out in the direction of the front of the drone.
● Once the panel is out, gently pull on it to get the cable out.
● Disconnect the cable by gently pushing down the lever of the connector while wiggling it to unplug.
● Only one cable is connected on the outermost panels.
● On the central (near the camera) panel you have two cables. The one with the red ring must be
connected to the connector closest to the camera.
● Take the new LED panel.
● Connect the cable (or cables).
● Slide the panel in. Pay attention to the panel sliding above the plastic tabs and under the plastic frame.
● Place the top and down screws and tighten them. Don’t apply extreme force, just enough to block the
screw in place.
● Connect the system to check that the LED works again.
ONLY USE FLYABILITY GENUINE REPLACEMENT PARTS.
To learn more about this topic, please watch the related support video. Support videos can be found here.
