ELIOS 2 system description
ELIOS 2 USER MANUAL Page 10 of 106
POWER BUTTON
Turns the Controller on/off and displays the battery level of the controller. Tap once to view the battery
level, tap again, and hold to turn on or off.
STATUS INDICATOR
Indicates the connection status between the controller and Elios:
-
Solid red: Controller is on, set as Master but not connected to the aircraft
-
Blinks blue: Controller is attempting to bind to the aircraft
-
Solid green: Controller is set as Master and connected to the aircraft
-
Solid purple: Controller is on, set as Slave, but not connected to the aircraft
-
Solid cyan: Controller is set as Slave and connected to the aircraft
-
Blinks red: Error. Use DJI GO (“before P4”) for further troubleshooting.
DJI GO WILL ASK YOU TO UPDATE THE FIRMWARE OF THE CONTROL UNIT.
DO NOT DO THIS. THE FIRMWARE VERSION OF THE CONTROLLER MUST
REMAIN AT VERSION 1.2.10
BATTERY LEVEL INDICATOR
Displays the controller’s battery level. Each LED corresponds to a 25% remaining charge.
DISTANCE LOCK
-
Short press: activates the distance lock mode. If a distance has been previously set and is within
±500mm from the current front distance, the aircraft will use this value. If not, the aircraft will use
the current front distance value.
-
Long press: activates the distance lock mode and resets the distance value to the current front
distance.
-
The set lock distance can be increased of decreased with the “forward/backward” control stick.
ALTITUDE MODE
Up: MANUAL THRUST CONTROL mode, gives direct control over the thrust
Down: ALTITUDE CONTROL mode, the altitude is automatically maintained.
An onboard pressure sensor measures the altitude of the drone. In some cases, the pressure in an
environment will not be stable, and ELIOS 2 will not be able to maintain a constant altitude. To have
better control, the pilot can disable the Automatic Altitude Control mode to have direct control on the
motors’ thrust, called Manual Thrust Control. In this case, instead of controlling the height, the up/down
stick will regulate the thrust power. Operating in Manual Thrust Control mode is not covered by the
warranty.
CAM TILT
Controls the tilt of the camera:
-
Clockwise, the camera looks upward.
-
Counterclockwise, the camera looks downward.
CAM TILT RST
Horizontally levels the camera when pressed
FN BUTTON
Press and hold this button to use secondary functions of other buttons
EV | LIGHTING PWR | FRT LIGHT WHEEL
Wheel:
-
Default: scrolling sets the EV of the camera, pressing the wheel resets EV to 0
-
While the FN button is pressed the wheel sets the onboard lighting intensity
-
While the FN button is pressed, pressing on the wheel turns on automatic or off the Close up panel
LEDs
FLIGHT MODE SWITCH
This 3 position switch selects the flight mode of the drone.
