Flyer UPROC - Indicators and settings on the on-board computer; Setting the assistance level

17
EN
Colourof
indicator d
Meaning
white
Thee-bikebatteryisover30%
charged
yellow
Thee-bikebatteryisover15%
charged
red
The capacity for assisting the
drive has been used up, and
assistanceis switched o󰀨. The
remaining capacity will be pro
-
vided for the bike lights and the
on-board computer
.
If the e-bike battery is being charged on the wheel,
acorrespondingnoticationwillbedisplayed.
If the on-board computer is removed from the
holder(5), the state of charge that was last dis-
played for the battery is saved.
Setting
theassistancelevel
On the operating unit (7), you can set the level of
assistance you want the e-bike drive to provide
you with while pedalling. The assistance level can
be changed at any time, even while cycling.
Note: In some models, the assistance level may be
preset and cannot be changed. There may also be
fewer assistance levels available than stated here.
The following assistance levels are available as
amaximum:
– OFF: Motor assistance is switched o󰀨. The
e-bike can just be moved by pedalling, as with
a normal bicycle. The push assistance cannot
be activated at this assistance level.
– ECO: E󰀨ective assistancewithmaximum e󰀩
-
ciency,
formaximumrange
– TOUR: Steady assistance, long range for tour-
ing
– SPORT/eMTB:
– SPORT: Powerful assistance, for mountain bik-
ing
andcyclinginurbantra󰀩c
– eMTB: Optimum assistance whatever the ter-
rain, rapid acceleration when starting from a
standstill,
improved dynamics and top perfor-
mance (eMTB only available in combination
with the
drive units BDU250P CX, BDU365,
BDU450 CX and BDU480 CX. A software up-
date may be required.)
– TURBO: Maximum assistance even at high
pedalling speeds, for sport cycling
To increase the assistance level, press the + (12)
button on the operating unit repeatedly until the de-
sired assistance level appears on the display. To de-
crease the assistance level, press the – (11) button.
The requested motor output appears on the dis-
play h.
Themaximummotoroutputdependson
the selected assistance level.
If the on-board computer is removed from the
holder (5), all values for the functions are saved
and can still be scrolled through.
IftheKioxbatteryisnotrecharged,thedateand
timewillberetainedforuptosixmonths.When
the on-board computer is switched on again, the
date and time will be reset if a Bluetooth
®
con-
nection to the app has been established and the
smartphone
 has successfully identied the cur-
rent location via GPS.
The Kiox only charges while it is
switched on.
IftheKioxisswitchedo󰀨duringcharging
viaa USB cable, the Kioxcan only be
switched on again once the USB cable
has been disconnected.
Tomaximisethelifespanoftheon-board
computer’s battery, it should be recharged
for one hour every three months.
Storagemode/resettingtheKiox
The on-board computer has an energy-saving
storage mode which minimises the rate at which
the internal battery discharges. Setting to this
mode erases the date and time.
This mode can only be activated by pressing and
holdingtheon/o󰀨button(4) of the on-board com
-
puter for at least eight seconds.
If the on-board computer does not start when the
on/o󰀨
button (4) ispressedbriey,theon-board
computer is in storage mode.
You can deactivate storage mode by pressing the
on/o󰀨button(4) for at least two seconds.
The on-board computer detects whether it is in
a fully functional condition. If you press and hold
the on/o󰀨 button (4) for at least eight seconds
while in a fully functional condition, the on-board
computer will go into storage mode. If, contrary to
expectations,theKioxisnotinafullyfunctional
condition and cannot be operated, pressing and
holdingtheon/o󰀨button(4) (for at least eight sec
-
onds) will reset it. After being reset, the on-board
computer
 will restart automatically after approx.
veseconds. If theKioxdoesnot restart, press
theon/o󰀨button (4) for two seconds.
To reset the Kiox to its factory settings, select
<Settings> → <Sysettings> → <Factory re
-
set>. All user data will be lost.
Battery
chargeindicator
The battery charge indicator of the e-bike battery
d (see “Start page”, page English – 19) can be
read on the status page and in the status bar. The
e-bike battery’s state of charge is also indicated
by the LEDs on the e-bike battery itself.
