No. Menu name Specification Description
14_15_
6
Alarm text input 6 WritableCentral System TextAlarm
text input 6
Alarm text to use for general input 6.
14_15_
7
Alarm text input 7 WritableCentral System TextAlarm
text input 7
Alarm text to use for general input 7.
14_15_
8
Alarm text input 8 WritableCentral System TextAlarm
text input 8
Alarm text to use for general input 8.
14_16 Alarm code filter... Read only Menu group for alarm code filter
14_16_
1
Alarm code input 1 Writable Alternative alarm code to use for general input 1
14_16_
2
Alarm code input 2 Writable Alternative alarm code to use for general input 2
14_16_
3
Alarm code input 3 Writable Alternative alarm code to use for general input 3
14_16_
4
Alarm code input 4 Writable Alternative alarm code to use for general input 4
14_16_
5
Alarm code input 5 Writable Alternative alarm code to use for general input 5
14_16_
6
Alarm code input 6 Writable Alternative alarm code to use for general input 6
14_16_
7
Alarm code input 7 Writable Alternative alarm code to use for general input 7
14_16_
8
Alarm code input 8 Writable Alternative alarm code to use for general input 8
14_17 Test alarm... Read only Menu group for test alarm
14_17_
1
Test alarm
intervaldays
Writable Test alarm interval. How often the test alarm shall be sent.
14_17_
2
Test alarm time Writable Test alarm time. The time of the day, at which the test alarm is sent.
14_17_
3
Test alarm state Writable Alternative0 = Off1 = On Manual activation of the test alarm.Also reflects the current state of the
test alarm.
15 Communication...
(Card not installed)
Read only Menu group for communication with the Central system/SMS.
15_1 Station number / id Writable The unique number of the station within the system.
15_2 Station name WritableCentral System TextStation
name
Enter the station name. This name will be used in SMS calls to a GSM
telephone.
15_3 Telephone no.
CS/SMS
WritableCentral System
TextTelephone number to Central
system / SMS
Telephone number to central system or SMS receiver. T=Tone dial.
The telephone number is required for alarm handling to the central
system or SMS receiver.
15_4 Telephone no. SMS 2 WritableCentral System
TextTelephone SMS 2
Telephone number to SMS receiver. The telephone number is
required for alarm handling to more than one SMS receiver.Only
applicable when alarm handling using SMS is selected.
15_5 Telephone no. SMS 3 WritableCentral System
TextTelephone SMS 3
Telephone number to SMS receiver. The telephone number is
required for alarm handling to more than one SMS receiver.Only
applicable when alarm handling using SMS is selected.
Appendix A: RTU Descriptions
54 APP 541 User manual
