No. Menu name Specification Description
15_6 Telephone no. SMS 4 WritableCentral System
TextTelephone SMS 4
Telephone number to SMS receiver. The telephone number is
required for alarm handling to more than one SMS receiver.Only
applicable when alarm handling using SMS is selected.
15_7 Telephone no. SMS 5 WritableCentral System
TextTelephone SMS 5
Telephone number to SMS receiver. The telephone number is
required for alarm handling to more than one SMS receiver.Only
applicable when alarm handling using SMS is selected.
15_8 SMS Acknowledge
time min
WritableCentral System TextSMS
Acknowledge time (min)
The time the RTU waits for an acknowledge re-calling or SMS before
sending the SMS alarm to the next telephone number in the list.0 -
disables the function. I.e. the SMS is send directly to all valid
telephone numbers.Only applicable when alarm handling using SMS
is selected.
15_9 SMS P-alarm Writable Alternative0 = No1 =
YesCentral System TextSMS P-alarm
Send SMS on deactivation of an alarm.Only applicable when alarm
handling using SMS is selected.
15_10 Communication
COM1
Writable Alternative0 = None1 =
Hayes modem2 = GSM/Hayes
predefined3 = RS232 HDX4 =
RS232 FDX5 = User modem6 =
GPRS
Type of communication to use for the communication with the Central
System/SMS.
15_11 Modem init 1 Writable Initialization string for the modem. (part 1)Applies only when 'User
modem' is selected as communication.
15_12 Modem init 2 Writable Initialization string for the modem. (part 2)Applies only when 'User
modem' is selected as communication.
15_13 Speed COM1bps Writable Alternative0 = 12001 =
24002 = 48003 = 96004 =
192005 = 384006 = 576007 =
115200
Speed to use for the communication with the Central System.
15_14 Parity COM1 Writable Alternative0 = None1 =
Even2 = Odd
Parity COM1
15_15 Protocol COM1 Writable Alternative0 = AquaCom
polled fixed1 = AquaCom dialled2
= AquaCom/SMS3 = Modbus
fixed4 = Modbus dialled5 = Comli
fixed6 = Comli dialled7 =
AquaCom unpolled fix
Choice of transmission protocol to use for the communication with the
Central System/SMS.
15_16 RTS delay COM1 ms Writable Delay for the RTS signal (request to send) in the communication with
the Central System. Only in choice of RS 232 HDX.
15_17 CS IP address Writable The IP address to the Central System.Applies to communication with
GPRS only
15_18 CS IP port Writable The IP port of the Central systemApplies to communication with GPRS
only
15_19 Access point name 1 Writable Access point name. (part 1)Applies to communication with GPRS only
15_20 Access point name 2 Writable Access point name. (part 2)Applies to communication with GPRS only
15_21 Max buffer sizebytes Writable Limits the data size when collecting trend.
16 General... Read only Menu group for general set-points
16_1 Date and time Writable Setting of date and time.
Appendix A: RTU Descriptions
APP 541 User manual 55
