No. Menu name Specification Description
17_4_2 Com. alarm activ. 1 Writable Alternative1 = Mains
error2 = Low 24V Supply3 =
Sensor Fault4 = Inval.setpoints5 =
Blocked6 = High level float7 =
High level8 = Low level float9 =
Low level10 = High level+pfail11
= Failure 2 pumps12 = Tripped
motor P113 = Tripped motor P214
= Tripped motor P315 = Tripped
motor P416 = No response P117 =
No response P218 = No response
P319 = No response P4
Selects which alarms that activates the common alarm output. (part 1)
17_4_3 Com. alarm activ. 2 Writable Alternative1 = High
current P12 = High current P23 =
High current P34 = High current
P45 = Low current P16 = Low
current P27 = Low current P38 =
Low current P49 = P1 max run
time10 = P2 max run time11 = P3
max run time12 = P4 max run
time13 = P1 switched off14 = P2
switched off15 = P3 switched off16
= P4 switched off17 = High temp.
P118 = High temp. P219 = High
temp. P320 = High temp. P4
Selects which alarms that activates the common alarm output. (part 2)
17_4_4 Com. alarm activ. 3 Writable Alternative1 = P1 Spare
alarm2 = P2 Spare alarm3 = P3
Spare alarm4 = P4 Spare alarm5 =
Alarm input 16 = Alarm input 27 =
Alarm input 38 = Alarm input 49 =
Alarm input 510 = Alarm input 611
= Alarm input 712 = Alarm input
813 = High capacity P114 = High
capacity P215 = High capacity
P316 = High capacity P417 = Low
capacity P118 = Low capacity P219
= Low capacity P320 = Low
capacity P4
Selects which alarms that activates the common alarm output. (part 3)
17_4_5 Com. alarm activ. 4 Writable Alternative1 = Pers.
alarm2 = Overflow3 = High rain 5
min4 = High rain 24 h5 = Testcall !
6 = I/O-mod not resp7 = Wrong
I/O-module8 = Setpoint changed
Selects which alarms that activates the common alarm output. (part 4)
17_5 General inputs... Read only Menu group for general inputs
17_5_1 Function gen.input 1 Writable Alternative0 = None1 =
P1 manual2 = Power failure3 =
External alarm4 = Blocking5 =
Personnel6 = Rain meter7 =
Overflow8 = Low level float9 =
High level float10 = High temp.
P111 = P1 Spare alarmCentral
System TextFunction general input
1
Select function for general input 1.Default is 'High temp. P1'
Appendix A: RTU Descriptions
APP 541 User manual 57
