FLYGT APP 541 - Page 61

No. Menu name Specification Description
17_5_8 Function gen.input 8 Writable Alternative0 = None1 =
P4 auto2 = Power failure3 =
External alarm4 = Blocking5 =
Personnel6 = Rain meter7 =
Overflow8 = Low level float9 =
High level float10 = High temp.
P411 = P4 Spare alarmCentral
System TextFunction general input
8
Select function for general input 8.Default is 'High level float'
17_6 I/O-module... Read only Menu group for I/O-module
17_6_1 Base IP address Writable Base IP address for the RTU and the I/O-module.2 consecutive
addresses are required. The first address is used by the RTU. The
second address is used by the I/O-module and does not have to be
entered.
17_6_2 I/O-mod. MAC
address
Writable The MAC address of the I/O-module
17_6_3 IP timeout Writable The timeout for the IP communication with the I/O-module.
17_6_4 I/O module type Read only Type of I/O-module.
17_6_5 I/O-module version Writable I/O-module version. The value is fetch from the I/O-module
17_7 Outputs... Read only Menu group for Outputs
17_7_1 Function output 4 Writable Alternative0 =
Motorprotect. reset1 = Sprinkler2
= General output
Select if the outputs is to be used as motor protection reset or general
purpose outputs.
17_7_2 Output 4 config. Writable Alternative1 = Power
failure2 = High level3 = P1
failure4 = P1 blocked5 = P2
failure6 = P2 blocked7 = P3
failure8 = P3 blocked
Select which signals that shall activate the output 4.Applies only if
general purpose outputs have been selected.
17_8 Diagnostic program Writable Alternative0 = Off1 =
1-39
Diagnostic program for test of the RTU
17_9 Flygt default Writable Alternative0 = No1 = Yes Resets all settings to default.
18 Show more menus Writable Alternative0 = No1 = Yes Shows hidden menus
19 Show more menus
(password)
Writable Shows hidden menus when password function is enabled. Enter
password!
20 ¤ Language Writable Alternative0 = English1 =
Deutsch2 = Nederlands3 =
Français4 = Dansk5 = Svenska6 =
Norsk7 = Español8 = Magyar9 =
Suomi10 = Italiano11 =
PycckNN12 = Polski13 = English
US
Select display language.
