Program Program
Code Function Code Description Entry Code
20 Issue/Rev. 03 (8/97)
044 Additive Injector Enter: Four digit number indicating 044
#8 Plumbing the products that this additive
injector is plumbed into.
1st digit - Product #1
2nd digit - Product #2
3rd digit - Product #3
4th digit - Product #4
A zero in the digit indicates
that the injector is not plumbed
into that product, a one indicates
that the injector is plumbed
into that product. (e.g., 1110
indicates that the injector is
plumbed into products 1, 2,and 3.) __ __ __ __
Note: If that additive injector output is configured for use and this entry is "0000" the indication is that it is plumbed into the loading arm downstream
of the metering system.
045-089 Unassigned at Present 045-089
090 Input/Output Enter: "1" One Product 090
Configuration "2" Two Products
"3" Three Products
"4" Four Products __
Warning: If you have already programmed codes 001 through 045, do not program this code. It may change what
you have already programmed.
Note: Entering the above number will program the AccuLoad II to a typical Input and Output configuration for the number of products selected.
Refer to manual MN06066L for input and output assignments when using this method of configuring the AccuLoad II-RBU.
091 Print Enter: Press "ENTER". The output configuration 091
Configuration will be displayed. Press "ENTER". The
input configuration will be displayed.
Press "ENTER" again to print the
configuration report.
092-099 Unassigned at Present 092-099
