Program Program
Code Function Code Description Entry Code
50 Issue/Rev. 03 (8/97)
873 Maximum Units Enter: Five digits in tenth 873
4-20 Channel #3 units for maximum units at 20 mA.
(e.g., 450.0) __ __ __ __ . __
Note: If the channel is selected for temperature the first digit entered is the sign + or -. Where 0 = +, 1 = -.
874 Minimum Units Enter: Five digits in tenth 874
4-20 Channel #4 units for minimum units at 4 mA.
(e.g., 160.0) __ __ __ __ . __
Note: If the channel is selected for temperature the first digit entered is the sign + or -. Where 0 = +, 1 = -.
875 Maximum Units Enter: Five digits in tenth 875
4-20 Channel #4 units for maximum units at 20 mA.
(e.g., 450.0) __ __ __ __ . __
Note: If the channel is selected for temperature the first digit entered is the sign + or -. Where 0 = +, 1 = -.
876-899 Unassigned at Present 876-899
900 System Diagnostic Directory 900
901 Diagnostic Display Test None 901
902 Diagnostic Keypad Test None 902
903 Diagnostic RTD #1 & #2 Test None 903
904 Diagnostic 4 - 20 mA Channel 1 & 3 None 904
905 Diagnostic 4 - 20 mA Channel 2 & 4 None 905
906 Diagnostic Internal Temperature None 906
907 Diagnostic Power Supply Test None 907
908 Diagnostic Firmware Version None 908
