FMC Technologies AccuLoad II - Product Volume Accuracy Directory; Minimum Batch Volume; Meter Factor #1

Program
Code Function Code Description Prod 1 Prod 2 Prod 3 Prod 4
56 Issue/Rev. 03 (8/97)
281 Flow Adjustment Enter: Three digits in tenths of a second
Timer for the flow rate adjustment tolerance
to be in effect (e.g., 03.0). __ . __ __ . __ __ . __ __ . __
Note: This code is used in conjunction with code 280, if code this code is programmed "000" this function is disabled.
282-299 Unassigned at Present
300 Product Volume Accuracy Directory
301 Minimum Batch Enter: Five digits in
Volume whole units (e.g., up
to 99,999 units) _______ _______ _______ _______
302-339 Unassigned at Present
340 Protection of Program Enter: "0" for Weights and Measures Mode
Codes 380-389 "1" for Program Mode __ __ __ __
341 Flow Rate for Enter: Four digits in whole units
Meter Factor #1 per minute (e.g., 0600) _____ _____ _____ _____
342 Meter Factor #1 Enter: Five digits as one whole
number followed by four
decimals (e.g., 1.0033) _._____ _._____ _._____ _._____
343 Flow Rate for Enter: Four digits in whole units
Meter Factor #2 per minute (e.g., 0400) _____ _____ _____ ______
Note: If flow rate is set at zero the AccuLoad II will ignore codes 344 through 348.
344 Meter Factor #2 Enter: Five digits as one whole
number followed by four
decimals (e.g., 1.0040) _._____ _._____ _._____ _._____
345 Flow Rate for Enter: Four digits in whole units
Meter Factor #3 per minute (e.g., 0150) _____ _____ _____ _____
Note: If flow rate is set at zero the AccuLoad II will ignore codes 346 through 348.
