FMC Technologies AccuLoad II User Manual

Program
Code Function Code Description Prod 1 Prod 2 Prod 3 Prod 4
Issue/Rev. 0.3 (8/97) 55
205 Flow Tolerance Enter: One digit as a percentage of
First High Flow Rate (e.g., 7) __ __ __ __
206 Zero Flow Timer Enter: Two digits in seconds (e.g., 15)
"00" disables the alarm __ __ __ __ __ __ __ __
207 First Trip Volume Enter: Four digits in whole units
(e.g., 0050) _____ _____ _____ _____
208 Final (Second) Trip Enter: Three digits in tenth units
Volume (e.g., 01.0) ___._ ___._ ___._ ___._
209 Final (Second) Trip Enter: One digit which defines
Auto Adjust the number of runs to average.
(e.g., 3) __ __ __ __
210 Low Flow Rate Alarm Enter: Three digits in whole
Limit units per minute (e.g., 050)
"000" disables the alarm ____ ____ ____ ____
211 PT/VF Time Delay Enter: Two digits in seconds
of time delay (e.g., 15)
Entry must not be "00" __ __ __ __ __ __ __ __
212-239 Unassigned at Present
240 Protection of Program Enter: "0" for Weights and Measures Mode
Codes 280-289 "1" for Program Mode __ __ __ __
241 Flow Control Valve Enter: "0" for No Security
Security "1" for Security __ __ __ __
242-279 Unassigned at Present
280 Flow Adjustment Enter: Two digits as a +/- percentage
Tolerance of the programmed or calculated flow
rate. (e.g.,+/-3.0). __ . __ __ . __ __ . __ __ . __
Note: This code is used in conjunction with code 281, if code 281 is programmed "000" this function is disabled.
