Program Program
Code Function Code Description Entry Code
Issue/Rev. 0.3 (8/97) 35
703 EIA-232 Baud Rate Enter: "0" for 110 Baud 703
"1" for 150 Baud
"2" for 300 Baud
"3" for 600 Baud
"4" for 1200 Baud
"5" for 2400 Baud
"6" for 3600 Baud
"7" for 4800 Baud
"8" for 7200 Baud
"9" for 9600 Baud __
704 EIA-232 Data Format Enter: "0" EIA-232 7 Bits Even 704
"1" EIA-232 7 Bits Odd
"2" EIA-232 7 Bits None
"3" EIA-232 8 Bits Even
"4" EIA-232 8 Bits Odd
"5" EIA-232 8 Bits None __
705 EIA-485 Enter: "0" No Communications 705
Communication "1" EIA Type Terminal
Type "2" EIA Type Minicomputer __
706 EIA-485 Enter: "0" for Polling Only 706
Communication "1" for Poll and Authorize
Control "2" for Remote Control
"3" for Auto Out
"4" for Shared Auto Out __
707 EIA-485 Baud Rate Enter: "0" for 110 Baud 707
"1" for 150 Baud
"2" for 300 Baud
"3" for 600 Baud
"4" for 1200 Baud
"5" for 2400 Baud
"6" for 3600 Baud
"7" for 4800 Baud
"8" for 7200 Baud
"9" for 9600 Baud __
