EPE2-Controller for Meter Draining System
EPE2
Installation Manual
Sening®
Innovative Tank Truck Systems
18 Rev. 1.03 / JS / jp / March 2010 MN F08 003 US / DOK-450E
3.6 Components overview
3.6.1 Control board REC-1S
Figure 6: Control board REC-1S
3.6.2 EPE2-Controller Internal overview
SVC-2S power supply board REC-1S control board
SVC-2S
DIP switch S1
SVC-1S
DIP switch S1
JP4
JP5
J1 solenoid valve
connection
J3 sensor connection
J6 PC or Laptop
Figure 7: EPE2-Controller Internal overview
