3.8.5 Sensor interface
The diagnostic function for the sensor interface is contained in menu 4.3.8. For every sensor input
used, the corresponding sensor status is displayed. The statuses of the sensor inputs not used in
the configuration are indicated with '-'.
This menu item can be actuated only when the connection to the sensor interface is active.
Diagnosis Sensor-Interface Menu 4.3.8
Possible statuses:
0 - open,
1- closed,
2 - interrupted,
3 - = short-circuited
Press the <F1> key to initiate
an update of the overall status
display. Under normal circum-
stances this is not necessary
however because all statuses
are updated automatically as
soon as they have been de-
tected by the MultiFlow. There
is a short delay between the
change in status and the display updating due to the internal evaluation logic.
The diagnosis function can be used only when the connection to the sensor in-
terface is active.
There is a short delay between the change in status and the display updating
due to the internal evaluation logic.
Status of the
used sensor inputs
No. No. No.
-------------------
1 0 2 1 3 -
4 - 5 - 6 -
7 - 8 - 9 -
10 1 11 - 12 -
13 - 14 - 15 -
16 - 17 - 18 -
