User manual
Chapter VII technical specification
7.1 General data
1.Power supply: 15V/2000mA
2.Built in rechargeable battery:11.1V/1000mah
3.System static current: <50mA(exclude wireless detector)
4.System alarming current: <300mA(exclude wireless high siren
current)
5.System maximum output current: 100mA(supply wireless
detector)
6.Frequency:433MHz/868MHz
7.Signal transmit distance: 100 to 150 meters (open area)
8.The method of alarming dial: DTMF GSM or GPRS
9.Communication protocol with CMS: Ademco Contact ID
10.DTMF dial frequency variation:,1.5%
11.Recording time:15s
7.2 Physical performance
Operation temperature range: 0 -45 (32F-120F
Storage temperature range: -20 -60 (-4F-140F)
Relative humidity: 85% at 30 (86F)
Color: as box indicated.
