2.1
1.
2.
3.
Installation
Fix the bracket to the wall and hang the pane to the bracket
The large metal objects can not be placed around the panel, so as not to
affect the wireless signal.
Make sure to place the panel within the wireless range of all wireless
accessoris and pay attention to the hidden
2.2 Connection(N.O. N.C)
LINE
TELL
DC15V/2A
Power
PGM GND Z33 Z34 GND Z35 Z36 Z37 Z38 GND Z39 Z40
Here only introduce the zone 33, 34, 37, 38. The other zones please
2.3 Install wired detector
2.3.1The wired zones is disabled factory default. when to use wired zones
please enable the zones firstly.When wired zones is in trouble, the
panel will voice prompt "operation fails, Zone trouble if users try
4
User manual
N.ON.C
As pictures
Chapter 2 Installation and Connection
Voice volume
knobs
refer to the above.
