Forcepoint 330 - Model 335 and 335 W Hardware Features; Front Panel Overview

Forcepoint Next Generation Firewall Hardware Guide | Models 330, 331, 335, 335W
6
Model 335 and 335W features
The figures and tables show the appliance components.
Front panel
The front panel includes indicator lights and ports.
3 5 7
4
8 9
6
1 2
1 Interface module slot 1
2 Interface module slot 2
3 Power button
The indicator on the button shows if the power is on.
4 Indicator lights
5 Console port (speed 115,200 bps)
6 USB port
7 USB 3.0 port
8 Fixed Ethernet ports 0-3
The ports belong to slot 0 and they are numbered eth0_0, eth0_1, eth0_2, and eth0_3 from left to right.
9 Fixed Ethernet ports 4-7
The ports belong to slot 0 and they are numbered eth0_4, eth0_5, eth0_6, and eth0_7 from left to right.
