Forcepoint Next Generation Firewall Hardware Guide | Models 330, 331, 335, 335W
8
Number Indicator Status Description
Red The appliance is in a standby state.
Flashing amber Initial contact between the NGFW Engine and
the Management Server has not yet been
established.
Solid amber The NGFW Engine is in the offline state for one
of the following reasons:
• Initial contact between the NGFW Engine
and the Management Server has been
established but the NGFW Engine is not yet
processing traffic.
• The NGFW Engine has been commanded to
go offline.
2 Software status
Green The NGFW Engine is in the online state and
processing traffic.
3 Management
connectivity
Green A network connection between the NGFW
appliance and the Management Server has
been established.
4 Wireless status
(Model 335W only)
Green The wireless interface is configured as a
wireless access point and is active.
Ethernet port names
Ethernet port names are based on the slot and port numbers.
The first number in the name represents the slot on the appliance. The second number represents the port on the
slot. For example, eth2_0 is located on port 0 of slot 2.
Component Slot number Port numbers
Fixed Ethernet ports 0 eth0_0, eth0_1, eth0_2, eth0_3, eth0_4,
eth0_5, eth0_6, and eth0_7 from left to
right.
Interface module
ports
1–2 from left to right The port numbers start from 0 and increase
from left to right. For example, the port
farthest to the left in slot 1 is eth1_0.
