122
[IP07400( X)07/94]
VENT Button
[IP07500( X)03/95]
Push this button to select outside air through the instrument
panel registers. The display window will show the set
temperature and VENT to the lower right of the temperature.
Your EATC will heat the air if the temperature you have
selected is warmer than the outside air coming into the vehicle.
However, the air will NOT be cooled regardless of the
temperature setting. Airflow will be from the instrument panel
registers.
[IP07600( X)03/95]
PNL & FLR Button
*
[IP07700( X)03/95]
Push this button to get air from the floor and instrument panel
registers at the same time. The display will show the set
temperature and the words PNL and FLR. Depending on the
selected temperature, the air will be automatically heated or
cooled.
[IP07800( X)07/94]
FLOOR Button
[IP07900( X)03/95]
Airflow will be to the floor when the FLOOR button is pressed.
The display window will show the set temperature and FLR to
the left of the temperature. The air cannot be cooled in the
FLOOR position, only heated. Fan speed will be automatic
unless manually controlled. If you override the fan speed and
wish to return to automatic fan control, push AUTOMATIC.
Then, again select FLOOR for airflow to the floor.
[IP08000( X)07/94]
FLR & DEF Button
[IP08100( X)03/95]
Push this button to get air to the floor and windshield
defrosters at the same time. The display will show the set
temperature, FLR and V symbol to indicate FLR & DEF has
been selected. If the outside temperature is about 50˚F (10˚C) or
warmer, the air will be dehumidified to remove moisture. This
will help to prevent fogging in humid weather.
