92
[LG10300(ALL)10/94]
6 pica art:0020752-E
Fuel gauge — mechanical cluster with tachometer
%
*
[LG11100(ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG11201(ALL)03/95]
This gauge tells you the temperature of the engine coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indicator will not be accurate.
*
[LG11301(ALL)08/95]
The pointer moves from the C (cold) mark into the Normal
band as the engine coolant warms up. It is acceptable for the
pointer to fluctuate within the Normal band under normal
driving conditions. Under certain driving conditions, such as
heavy stop and go traffic or driving up hills in hot weather, the
pointer may move to the top of the Normal band.
*
[LG11401(ALL)05/95]
If, under any circumstances, the pointer moves above the
NORMAL band, the engine coolant is overheating and
continued operation may cause engine damage.
*
[LG11501(ALL)01/95]
If your engine coolant overheats:
*
[LG11601(ALL)03/95] 1. Pull off the road as soon as it is safely possible.
*
[LG11701(ALL)03/95] 2. Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG11801(ALL)05/95] 3. Let the engine cool. DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
*
[LG11901(ALL)04/95] 4. Check the coolant level following the instructions on
checking and adding coolant to your engine. Refer to Engine
coolant in the Index. If you do not follow these instructions,
you or others could be injured.
