Toshiftfrom4WDAUTOor2WDto4WDLOW:
[DR18290( X)01/95]
Stop the vehicle, depress the brake and place the automatic
transmission in N (Neutral) or depress the clutch on vehicles
with a manual transmission. Rotate the 4WD switch on the
instrument panel to 4WD LOW. Both the 4WD and 4WD LOW
lights are now lit.
[DR18293( X)06/95]
For Explorers equipped with Automatic Ride Control:
[DR18294( X)06/95]
After shifting to 4WD LOW, wait about 90 seconds. This will
improve ground clearance and off-road handling. Refer to
Automatic Ride Control in the Features chapter.
[DR18320( X)08/94]
To shift from 4WD LOW to 4WD AUTO or 2WD:
[DR18400( X)01/95]
Stop the vehicle, depress the brake and place the automatic
transmission into N (Neutral) or depress the clutch on vehicles
with a manual transmission. Rotate the 4WD switch on the
instrument panel to 4WD AUTO or 2WD.
[DR18500(ALL)03/95]
It is not recommended to operate the vehicle in the 4WD modes
with a temporary spare. If 4WD operation is necessary, do not
operate at speeds above 10 mph or for distances above 50 miles.
Extended operation in 4WD with a temporary spare may result
in damage to drivetrain components.
[DR18600( X)12/95]
All-Wheel Drive System (If equipped)
[DR18620( X)12/95]
If your vehicle is equipped with All-Wheel Drive (AWD), power
is constantly supplied to all four wheels through a transfer case.
The AWD system is full-time and has no external controls.
[DR18630( X)12/95]
The AWD transfer case utilizes a viscous clutch that distributes
torque to the front and rear differentials (approximately 35%
front and 65% rear). The viscous clutch is filled with a
high-viscosity fluid, see
Lubricant Specifications
in the
Servicing
Your Explorer
chapter for more information.
