10. Remove the four fasteners on each
side of your vehicle that secure the
rear roof panel to the vehicle using
the provided head driver and ratchet.
11. With the tailgate window open, grab
the opening with one hand and
slightly lift with the other hand. Lift
the rear roof panel straight up and
off. Place the rear roof panel on a soft
surface to prevent damage.
Note: Store the rear roof panel with the
tailgate window open to prevent damage
to the glass seal.
12. To install, reverse the removal
procedure. Torque the fasteners that
secure the rear roof panel to your
vehicle to 15 ± 2 lb.ft (20 ± 3 Nm).
Note: Make sure the locating pins on the
rear roof panel sit flush in your vehicle when
installed.
Note: Do not overtighten the fasteners. You
can strip the fasteners if they are
overtightened.
REMOVABLE HARD TOP (IF
EQUIPPED)
REMOVING AND INSTALLING THE
HARD TOP
WARNING: When opening, closing,
removing or installing the removable
vehicle components, take care not to get
your fingers or hands caught in the
mechanism. Failure to follow this
instruction could result in personal injury.
1. Remove the roof panels. See
Removable Roof Panels (page 343).
2. To install, reverse the removal
procedure.
Removing the Soft Top Trim Piece
(If Equipped)
Make sure to remove the soft top trim
pieces before installing the hard top.
Remove the three fasteners to the soft top
trim piece on each side of your vehicle
using the provided head driver and ratchet.
347
2021 Bronco (TG1) Canada/United States of America, enUSA, Edition date: 202101, First-Printing
Removable Vehicle Components
