Note: As the seats slide rearwards, they
also move slightly inboard.
4. Pull the lever on the outer front edge
of the outboard seats and push the
seats rearwards.
To return the seats to the forward position,
pull the lever and slide the seats forwards.
To return the center seat to its original
position, pull the lever on the underside of
the seat. Fold the center seat forwards and
push it back down fully until it engages.
Install the luggage cover. See Luggage
Covers (page 167).
Folding the seatbacks down
WARNING
Do not place hot drinks in the cup
holders when the vehicle is moving.
Note: All three seatbacks can be folded
forward independently of one another.
Note: A table surface and cup holders are
located on the rear of the center seatback.
Remove the safety belts from the belt
guides on the outboard seatbacks. The
safety belt tongues must be inserted into
the retaining slots. See Fastening the
safety belts (page 28).
109
C-MAX (CB7)
Seats
