TECHNICAL SPECIFICATIONS
Vehicle dimensions
C-MAX
Dimension in mm (inches)Dimension description
4380 (172.4)Maximum length
2067 (81.4)Overall width including exterior mirrors
1595 - 1626 (62.8 - 64)Overall height - EC curb weight
2648 (104.2)Wheelbase
1544 - 1559 (60.8 - 61.4)Front track
1554 - 1569 (61.2 - 61.8)Rear track
Grand C-MAX
Dimension in mm (inches)Dimension description
4520 (177.9)Maximum length
2067 (81.4)Overall width including exterior mirrors
1653 - 1684 (65 - 66.3)Overall height - EC curb weight without roof bars
1667 - 1698 (65.6 - 66.8)Overall height - EC curb weight including roof bars
2788 (109.8)Wheelbase
1544 - 1559 (60.8 - 61.4)Front track
1554 - 1569 (61.2 - 61.8)Rear track
223
C-MAX (CB7)
Capacities and Specifications
