LUGGAGE COVERS
WARNING
Do not place objects on the luggage
cover.
Pull out the cover and secure it in the
retaining points.
Release it from the retaining points and let
it roll back into the case. Clip the retaining
hook onto the case.
To remove or install the cover, push either
end of the case inwards.
CARGO NETS
C-MAX
WARNING
Luggage retention net anchor points
are not fitted behind the first or
second row seats.
Grand C-MAX
WARNING
Luggage retention net anchor points
are not fitted behind the first row
seats, but are fitted behind the
second row seats.
Luggage retention net
Installing the net
CAUTIONS
Do not move the rear seats when the
cargo net is installed.
Do not use the cargo net if the third
row seats are in use.
167
C-MAX (CB7)
Load Carrying
