Green - 0.6 - 0.9 meter (24 - 35
inches)
D
Amber - center line of the
projected vehicle path
E
Note: The green line is extended from 0.9
meter (35 inches) up to a distance of 3.2
meters (126 inches).
Note: When reversing with a trailer, the lines
on the screen are not shown. The camera
will show the vehicle direction and not the
trailer.
Deactivating the rear view camera
Note: Disengage reverse gear. The display
will stay on for a short period before
switching off.
Note: The system will automatically switch
off once the vehicle speed has reached
approximately 15 km/h (9 mph).
Press the parking aid switch in the
instrument panel. For item location: See
At a Glance (page 9).
Vehicles with parking aid
The display will additionally show a
coloured distance bar. This guide indicates
the distance from the rear bumper to the
detected obstacle.
These are colour coded as follows:
• Green - 0.6 to 1.8 meters (24 - 71
inches).
• Amber - 0.3 to 0.6 meter (12 - 24
inches).
• Red - 0.3 meter (12 inches) or less.
153
C-MAX (CB7)
Rear view camera
