Circuits protected
Ampere
rating
Fuse
Heated windshield (left-hand side)4016
Fuel operated heater2017
Windshield wipers2018
Anti-lock Braking System, electronic stability program
module
519
Horn1520
Brake lamp switch521
Battery monitoring system1522
Relay coils, lighting control switch module523
Rear power outlet2024
Power exterior mirrors1025
Powertrain control module1526
Air conditioning clutch1527
Not used-28
Heated rear window2529
Powertrain control module530
Not used-31
Exhaust gas recirculation valve, swirl control valves, heated
exhaust gas oxygen sensor (engine management), elec-
tronic fan control module relay (coil), run on water pump
module - 1.0L EcoBoost
1032
Ignition Coils1033
Injectors1034
Intercooler relay coil535
Filter heater (diesel engine)1535
Powertrain control module1036
Not used-37
Powertrain control module, transmission control module1538
179
C-MAX (CB7)
Fuses
