Antenna PositionsMaximum output power Watt (Peak
RMS)
Frequency Band
MHz
3, 450 W1 – 30
1, 2, 350 W30 – 54
1, 2, 350 W68 – 87.5
1, 2, 350 W142 – 176
1, 2, 350 W380 – 512
1, 2, 310 W806 – 940
1, 2, 310 W1200 – 1400
1, 2, 310 W1710 – 1885
1, 2, 310 W1885 – 2025
Note: After the installation of RF
transmitters, check for disturbances from
and to all electrical equipment in the
vehicle, both in the standby and transmit
modes.
Check all electrical equipment:
• with the ignition ON
• with the engine running
• during a road test at various speeds.
Check that electromagnetic fields
generated inside the vehicle cabin by the
transmitter installed do not exceed
applicable human exposure requirements.
287
C-MAX (CB7)
Appendices
