Power (watt)SpecificationLamp

55H1Cornering lamp

55H11Front fog lamp

5W5WSide lamp

5WY5WSide repeater

5W5WApproach lamp

21PY21WRear direction indicator

21/5P21/5WBrake and tail lamp

5W5WTail lamp

21P21WRear fog lamp

21P21WReversing lamp

5W5WLicense plate lamp

5W5WCentral high mounted stop lamp

5W5WLuggage compartment lamp

Fit a replacement with the same rating as the one you have removed.
