2.3 Product components
2.3.1 Fuse 1
Print enclosure door: Provides access to the print enclosure and optical cassette tray.
IR sensor door: Provides top-down access to the IR sensor and powder card reader.
Touchscreen: The LCD capacitive touch user interface displays print information, settings,
and error messages.
Hopper lid: Prevents debris from entering and powder from leaving the hopper.
Hopper: Stores up to 9 kg (19.8 lb) of powder for printing.
Hopper window: Allows for visual check of powder level in the hopper.
Door handle: A grab slot to help close the door.
Cassette tray: Holds the optical cassette in place.
Build chamber latch: Secures a build chamber.
Print enclosure: Houses the build chamber and optics system for printing.
Build chamber socket: Connects the build chamber’s plug.
Filter cabinet door: Sealed door for accessing the intake and exhaust filters.
1
2
3
4
5
6
7
8
9
10
1 1
12
