Fort EXPLORER 180 - Techincal Specifications; Vibrations Level

29
1.5.2 VIBRATIONS LEVEL
The vibrations level was recorded with the engine
running at the max rpm. and is equal to:
VIBRATIONS m/s
2
HONDA GX 270 4,2
F 130 B /AE 4,6
LOMBARDINI LGA 340 4,4
LOMBARDINI 15LD 350 8,7
LOMBARDINI 6LD 400 9,5
F 70 B /AE 8,8
F120 D /AE 9,3
1.6 TECHNICAL SPECIFICATIONS
Engine:
Starter: recoil starter or electric starter on request at
the moment of order.
Accelerator: lever control on the handlebars.
Clutch: dry multi-disc with control on the handlebars.
Drive: oil-bath gear drive.
Change gear: 4 forward gears + 3 reverse gears
(with rotary hoe)
3 forward gears + 3 reverse gears
(with cutter bar)
PTO: independent (965 rpm).
Direction of rotation of PTO: clockwise (with rotary
hoe), counterclockwise (with cutter bar).
Safety devices:
- Special safety clutch that allows the movements
of the machine and the drive of the work tools
only with a “dead man”-type lever placed on the
handlebars (16, Fig. 1). The release of this lever
stops all machine functions without turning off the
engine.
- The clutch control lever has a particular automatic
locking system that prevents accidental insertion
of the clutch (to engage the clutch, two actions are
required: disengagement of the system locking the
lever (17, Fig. 1) and actuation of the lever (16 Fig.
1).
Handlebars: adjustable vertically and horizontally.
180° reversible.
Dimensions of wheels: 4.00x10 - 5.0x10 - 5.00x12
-6.5/80x12.
Wheel ination pressure: 2,2 bar.
Rotary hoe unit: cm. 60, or cm. 70 (possibility to
reduce it).
Overall dimensions: Please make reference to g.2.
Speed: Speed values were calculated with the engine
working at 3600 r.p.m.
Refuelling: For the type of fuel to be used, please
make reference to the engine handbook and check the
identication data on the name plate of the engine.
The fuel tank is under the engine casing.
NOTE: In the mower model, the speeds are reversed while keeping the same values.
WHEELS ROTARY HOE Forward gear km/h ROTARY HOE Reverse gear km/h
1
a
2
a
3
a
4
a
1
a
2
a
3
a
4,00 x 10 1,14 2,66 4,43 11,6 1,14 2,66 4,43
5,0 x 10 1,32 3,08 5,13 13,4 1,32 3,08 5,13
5,00 x 12 1,42 3,31 5,62 14,43 1,42 3,31 5,62
6,50/80 x 12 1,47 3,43 5,72 17,95 1,47 3,43 5,72
