NIRS™ DA1650
User Manual 6008 1286 / Rev. 8 3:1
3 Installation
3.1 Site Preparation
A Site Preparation Check List is available from your FOSS representative. This
document describes the necessary arrangements to be carried out or tested prior to
installation. If this has not been done in advance the check list items should be
considered during installation to ensure that the instrument is installed properly.
3.2 Unpacking and Checking
Unpack the NIRS DA1650 and its accessories with care. Save all packing material
for later use. Use the packing list provided with the instrument to check that all parts
are included.
An Installation Report is included with the accompanying documentation. Please
answer the questions in the Installation Report and return it to FOSS in the enclosed
postage paid envelope. If anything is damaged/missing or if you have any questions,
please contact your FOSS representative.
3.3 Lifting and Placement of the Instrument
Place the instrument on the workbench. The workbench should be as free from
vibrations as possible. Heavy vibrations can affect the analysis results.
Caution
The air circulation around the lamp cooling flange must not be
inhibited. Leave uncovered with sufficient space for air
circulation at all times.
3.4 Software Installation and Initial
Configuration
The NIRS DA1650 comes with the operating software ISIscan Nova already
installed on the embedded PC. Import and configuration of calibration models are
described in a separate Installation manual delivered with the instrument as a pdf-file
on the SW USB.
If purchased with FOSS calibrations/products they will already be installed and no
further configuration is required.
For changes to the pre-installed default configuration Mosaic Solo should be
connected as described in section
3.5 below.
