DMT-8 Ver 2.0 Supplement to the Owner’s Manual
30
General Structure=F0 51<device id><sub id 1>(<data>)F7
* Numbers are all expressed in hexadecimal units.
Command or Model Set
Controller to D-80/DMT-8 ver 2.0
Acknowledge or Status
D-80/DMT-8 ver 2.0 to Controller
Loop on/off
Post locate
Auto rec
Lock enable
Copy clip
Copy paste
Erase
Cut
Clipboard play
Undo
Redo
Nondes. mode
Move clip
Move paste
Digital in ch.
Digital out ch.
Program change
Click on/off
12 22 (<on/off>)
12 28 (<post locate moded>)
12 2D (<on/off>)
12 41 (<lock enable>)
12 45 (<count><mmc track>)
12 46 (<count=01><repeat count>)
or
12 46 (<count><repeat count><mmc track>)
12 47 (<count><mmc track>)
12 48
12 49
12 4A
12 4B
12 4C (on/off) * Refer to Note 1.
12 4D (<count><mmc track>)
12 4E (<count=01><repeat count>)
or
12 4e (<count><repeat count><mmc track>)
13 41 (<channel><channel>)
13 42 (<channel><channel>) *refer to note 2.
13 43 (<program>)
13 44 (on/off)
Fostex MIDI System Exclusive Message Format for D-80/DMT-8
ver 2.0
Following Protocol is effective only in equipment which will reply by -
Identity Reply=F0 7E<channel> 06 02 51 01 00 0A 00 01 00 7F 7F F7 (D-80)
Identity Reply=F0 7E<Channel>06 02 51 01 00 09 00 02 00 7F F7 (DMT-8 ver
2.0)
against the Inquiry Message=F0 7E<channel>06 01
< Note >
Fostex System Exclusive Message
32 2D (<edit message>)
32 45 (<edit message>)
32 46 (<edit message>)
32 47 (<edit message>)
32 48 (<sdit message>)
32 49 (<edit massage><mmc track>)
32 4A (<edit message>)
32 4B (<edit message>)
32 4D (<sdit message>)
32 4E (<edit message>)
Table: <sub id 1> (<data>)
