DMT-8 Ver 2.0 Supplement to the Owner’s Manual
32
<loop op.mode>
12=stop
Indicates the next operatinng mode following locating to the start point (GP3) upon
arriving at the end point (GP6) by the play mode. In D-80/DMT-8 ver2.0, 12=stop
only is effective.
12=stop
15=play
Specifies operating mode in which D-80/DMT-8 ver2.0 should enter pon
completung the locate operationi. Corresponds to the settinig of AUTO PLAY ON
("15")/OFF("12") on the main unit.
01~7F
Specifies succeeding data byte numbers.
Complies to the MMC (MIDI MACHIN CONTROL) standard track bit map. In D-80/
DDMT-8 ver2.0, you always need to specify two byte combinations of "r0" and "r1."
00 = no message
01 = completed (completion flag)
02 = active (executioin flag)
02<mmc time> = Indicates unprocessed time by active (execution flag) and <mmc
time>.
02<count><mmc track> = Indicates source track by acrive (execution flag)and
<mmc track>. Used for clipboard play.
03 = cancel (execution stop)
05 = Indicactes rehearsal (rehearsal mode of auto rec). Possible of undo.
06 = Indocates take (take mode of auto rec). Possible of undo.
10 = over value error
10<mmc time> = Capacity shortage time is indicated by over value erroe (error by
capacity shortage) and <mmc time>. In copy paste, it indicates capacty shortage
time required for a minimum one time paste.
11 = Indicates in point error (incorrect in point).
12 = Indicates out point error (incorrect out point).
14 = Indicates void data (data neccessary for paste does not exist).
18 = Indicates track select error (track necessary to execute copy/move) or erase/cut
is not correctl setup).
19<repeat count> = Indicates repeat number error and repeat number executable
by< repeat count>.
1A = Indicates disble rec (record disable mode).
25 = Indicates can undo rehearsal (rehearsal mode of auto rec). Impossible to
undo.
26 = Indicates can’t undo take (take mode of aauto rec). Impossible to undo.
71 = Indicates on.
72 = Indicates off.
hr mn sc fr {ff/st} complies to the MMC standard time code.
70 = default
71 = on
72 = off
01 ~ 7F
Especially when executing commands such as paste, the number of pasting times to
be continuously repeated following the auto punch in point is specified.
00 ~ 08
Selects tracks 1 ~ 8 of the reecorder sectioin. "00" means that no setup (sefalt setup)
is made.
00 = lock disable, chase disable
01 = lock enable, chase enable
Corresponds to SLAVE ON ("01")/OFF ("00") in the main unit.
00 = lock disable, chase disable
01 = lock enable (unloccked), chase enable (unlocked)
11 = lock enable (locked), chase enable (locked)
01 ~ 7F
Indicates program numbers (P1 ~ P5) on the main unit. However, D-80/DMT-8 can
specify only 01 (corresponds to P1) - 05 (corresponds to P5).
t1, t2 ...... tn
n: Indicates the track number.
tn: Indicates absolute 8 bits of the Auto 16 bit data (Range: 00~7F).
<post locate mode>
<count>
<mmc track>
<edit message>
<mmc time>
<on/offf>
<repeat count>
<channel>
<lock enable>
<lock status>
<program>
<level data>
Data Type
