16
10 [SOURCE SEL] switch
Selects the source signal of the [MAIN OUT] and
[SUB OUT] connectors. You can select the mas
-
ter stereo signal or the post-fader signals of input
channels 1 through 4.
Switch
position
MAIN OUT
(L/1, R/2)
SUB OUT
(L/3, R/4)
Notes
MIX
Stereo buss
(L, R)
Stereo buss
(L, R)
The stereo buss
signal is output.
DIRECT Inputs (1, 2) Inputs (3, 4)
The post-fader
si gna ls o f t he
input channels
are output.
<Note>: When you select the DIRECT position,
you cannot apply the limiter to the output signals
of the [MAIN OUT] connectors.
11. [TAPE OUT] jack
This jack outputs the unbalanced stereo buss sig-
nal. The reference level is fixed to -10 dBV.
Connector: 3.5 mm stereo mini-phone jack
12. [RTN] jack
This jack accepts a -10 dBV stereo signal.
Connector: 3.5 mm stereo mini-phone jack
13. [PHONES] jack
You can connect stereo headphones with the 3.5 mm
plug for monitoring.
You can monitor the same signal as the [PHONES]
jack in the front panel simultaneously.
Connector: 3.5 mm stereo mini-phone jack
