Layer 3 Upgrade Procedures
December 2008 © 2008 Foundry Networks, Inc. A - 3
Figure A.1 Top Cover Removal on FastIron Compact Switches
The following illustrations show the DIP key insertion and settings.
Remove these screws on
both sides of the device
Note: If rack mount ears are installed,
remove the four screws from each ear.
Rear
Front
Side
