Fourgroup Full-App 2 - 10. GENERAL SETTINGS; Filter Reading Coefficient Adjustment; Alarm Float (Hi-Flt Pumps ON) Functionality; Pump Start Delay Settings (P1-P2)

15
At this point the set of parameters associated to the input reading are complete. By pressing the button
it is possible
to return to the previous vertical parameter “Enable 4-20mA”:
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button :
To move to the next horizontal parameter press the button
:
Start Delay
P1-P2-P3 XXsec
Hi.Flt.Pumps ON
0=NO 1=SI X
Stop Delay
XXsec
Start Delay
P1-P2-P3 XXsec
The parameter “Start Delay P1-P2” will set a time delay on the re-start of the pumps after the
starting condition is met; for example, the activation of a start flow switch /pressure switch (for
operating modes Dark, Clean, Multitank) or once we have reached the level of activation for
signal 4-20 mA (for operating mode DIGIT). The first pump will start immediately; the start of
the second pump will be delayed accordingly by this set time value (start delay parameter).
The “X” indicates the digit of the parameter to modify.
The range of time delay start is from 4 to 99 seconds.
Factory default setting: 4 seconds.
Filter reading
Coeff. K: XXX
In parameter "Filter reading" you can increase / decrease the delay of the reading of 4-20 mA
signal: setting a low value reading signal will be faster, with a higher value will become slower.
Increase this coefficient is particularly useful in cases in which the reading signal (pressure /
Level) of the sensor becomes unstable maybe because of rapid changes in pressure / Level.
(The “X” indicates the digit of the parameter to modify).
The range of value is from 0 to 200.
Factory default setting: 50.
Hi.Flt.Pumps ON
0=NO 1=YES X
Enable 4-20mA
0=NO 1=YES X
Start Delay
P1-P2-P3 XXsec
Enable 4-20mA
0=NO 1=YES X
Delay Power Ret
0=RND XXXsec
Hi.Flt.Pumps ON
0=NO 1=YES X
In parameter " Hi.Flt.Pumps ON " you can decide the functionality of the alarm float. The alarm
float (or more generally a consensus alarm, that is a dry contact closure at which the alarm is
activated) must be physically connected to the Full-app framework (see section "Electric
connections").
The “X” indicates the digit of the parameter to modify:
1=YES: the activation of the alarm float you will have the alarm signal and depending on the
operating mode selected (see parameters menu "mode of operation") on emptying the start of
all pumps available (respecting the parameter "contemporary maximum pump ") while on filling
the stop of the pumps.
0=NO: the activation of the alarm float switch will cause only trigger the alarm signal.
Factory default setting: 0.
Hi.Flt.Pumps ON
0=NO 1=YES X
Stop Delay
XXsec
Start Delay
P1-P2-P3 XXsec
Enable Alarm
Voltage 0=NO X
