Fourgroup Full-App 2 - 10. GENERAL SETTINGS; Pump Self-Test and Time Settings; Manual Operation Modes Configuration

18
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
To move to the next horizontal parameter press the button
:
Self-Test pumps
0=NO XXX h
The parameter “Self-test pumps” will set the timer based value to be used by the Control Panel
full-app to execute all the pumps Functional Periodic Self-test (the periodic self-test is to avoid
the possibility the pumps might be blocked after being idle for a long period due to the
conditions of the system).
The “X” indicates the digit of the parameter to modify
The range of value is from 0 to 999 hours.
-0=NO: setting “0” the Pumps Self-test is disabled.
Factor
y
default settin
g
: 0.
Time test
Pumps XX sec
Self-Test pumps
0=NO XXX h
Tasto MANUALE
0=INSTABL X
Time test
Pumps XX sec
The parameter “Time Test Pumps” will set the duration of the self-test. In the situation where
the self-test is triggered on “minimum level open” (for the operating mode Dark, Clean,
Multitank) or trigger on the level of deactivation from signal 4-20 mA (for operating mode
DIGIT), the self-test will last at maximum 3 seconds regardless of the value set in this
parameter.
The “X” indicates the digit of the parameter to modify
The range of value is from 0 to 99 seconds.
Factory default setting: 5 seconds.
Note: the self-test will be executed with the following logic:
-start pump 1; operation for the time being set; stop pump 1; start pump 2; operation for the
time being set; stop pump 2.
Manual Mode
0=INSTABL X
Time test
Pumps XX sec
Turn-Off MANUAL
0=ON XXXsec
Manual Mode
0=INSTABL X
The parameter “MANUAL Mode” will set the operating mode of the buttons “MAN” for the
manual operation of the pumps.
The “X” indicates the setting of the parameter to modify
0=UNSTABL: setting “0” the MAN button should be pressed, this indicated “Operator Presence”:
the pumps will work while the button MAN is being pushed; when the button is released the
pumps will stop.
Setting “1” the operation of the pumps will continue for a programmable time (next parameter
“Turn-off MANUAL”) even after the release of the MAN button. When the timer elapses the
pumps will stop.
Factory default setting: 0.
Note: when using the mode “Operator Presence” the operation of the pumps will bypass the
protections that have been set (it is therefore necessary to verify that the manual operation will
not damage the pumps). On the other hand, the operation mode “Turn-Off MANUAL” is subject
to the protection settings.
Turn-Off MANUAL
0=ON XXXsec
Manual Mode
0=INSTABL X
Simultaneity
Max pumps nr.X
Turn-Off MANUAL
0=ON XXXsec
The parameter “Turn-off MANUAL” will set the operating time of the pumps after the button
MAN has been pressed (only if the “MANUAL Mode” has been set to “1”).
Shutdown requires pressing the button 0.
The “X” indicates the setting of the parameter to modify.
The range of value is from 0 to 999 seconds.
Factory default setting: 5 seconds.
Note: if it is set to “0” the operating mode will be “at continuous/infinite time” (the “Turn-Off
MANUAL” operating mode is subject to the protection settings).
