Foxconn H61MXV Series User Manual

1
3
Internal Connectors 2xSATA2.0connectors,2xSATA3.0connectors(H67MXV)
2xUSB2.0connectors(supporting4xUSBdevices)
1xCPUfanheader(4-pin)
1xSystemfanheader(4-pin)
1 x Front panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x SPDIF_OUT connector
1 x Buzzer (Co-lay Speaker connector)
1 x Chassis intrusion alarm header
1 x COM connector
1 x TPM connector
1 x LPT connector
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan speed control
PCI Express x1 SupportPCIExpressGen25GT/Sdatarate;
Low power consumption and power management features
PCI Express x16 SupportPCIExpressGen25GT/Sdatarate;
Low power consumption and power management features
Green Function SupportACPI(AdvancedCongurationandPowerInterface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),
S4(suspendtodisk),S5(soft-off)
Support EuP function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Operating System Support for Microsoft
®
Windows
®
7/Vista/XP/UBUNTU
Form Factor MicroATXFormFactor,9.6inchesx7.8inches(24.4cmx19.8cm)

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
