Foxconn H61MXV Series User Manual

3
26
► Package C State limit
It is used to select the C-State mode.
Performance Tuning
CPU Performance Tuning
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
EIST [Enabled]
Turbo Mode [Enabled]
1-Core Ratio Limit 24
2-Core Ratio Limit 24
3-Core Ratio Limit 0
4-Core Ratio Limit 0
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enhance Intel SpeedStep
Technology
Advanced
► EIST Function
You can select the EIST (Processor Power Management, PPM) through this item.
Enhanced Intel SpeedStep® technology (EIST) allows the system to dynamically
adjust processor voltage and core frequency, which can result in decreased average
power consumption and decreased average heat production. There are some system
requirements must be met, including CPU, chipset, motherboard, BIOS and operation
system. Please refer to Intel Website for more information.
C
A
U
T
I
O
N
!
► Turbo Mode (Display only when CPU supports)
Turbomodeallowsprocessorcorestorunfasterthanitsmarkedfrequencyinspeciccondi-
tion. It appears only when the “EIST” is enabled.
► 1-Core/2-Core/3-Core/4-Core Ratio Limit (Display only when CPU supports)
Whenthe“TurboMode”isenabled,thislimitisfor1/2/3/4coreactive.0meansusingthefac-
tory-conguredvalue.

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
