Chipset
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
North Bridge
ME Subsystem
←: Select Screen
↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
North Bridge Parameters
Chipset
► North Bridge/ME Subsystem
Press <Enter> to go to its submenu.
North Bridge
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Memory Information
Total Memory 1024 MB (DDR3 1333)
Memory Slot1 0 MB (DDR3 1333)
Memory Slot2 1024 MB (DDR3 1333)
VT-d [Disabled]
Initate Graphic Adapter [PEG/IGD]
IGD Memory [64M]
IGD Multi-Monitor [Disabled]
←: Select Screen
↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
VT-d Enable/Disable
Chipset
► Total Memory
This item displays the current using memory information.
► Memory Slot 1/2
These items display the memory size installed on each slot.
