Foxconn H61MXV Series User Manual

2
11
2-2 Install the Memory
Dual Channel Memory Conguration
This motherboard provides two DDR3 memory sockets and supports Dual Channel Technology.
When memory is installed, the BIOS will automatically check the memory in your system.
Two DDR3 memory sockets are divided into two channels:
Channel 0 : DIMM1,
Channel1:DIMM2,
The combinations of DIMM modules are :
Read the following guidelines before you begin to install the memory :
■ Makesurethatthemotherboardsupportsthememory.Itisrecommendedthat
memory of the same capacity, brand, speed, and chips be used.
■ Alwaysturnoffthecomputerandunplugthepowercordfromthepoweroutletbefore
installing the memory to prevent hardware damage.
■ Memorymoduleshaveafoolproofdesign.Amemorymodulecanbeinstalledinonly
one direction. If you are unable to insert the memory, switch the direction.
C
A
U
T
I
O
N
!
It is recommended that memory of the same capacity, brand, speed, and chips be
 usedandpleaseselectdualchannelrsttoachieveoptimumperformance.
C
A
U
T
I
O
N
!
DIMM1 DIMM2
Single Channel
DS/SS -
Single Channel
- DS/SS
Dual Channel
DS/SS DS/SS
(DS : Double Side, SS : Single Side, - : No Memory)

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
