Health
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Case Open Warning [Disabled]
CPU Temperature : +19 C
System Temperature : +30 C
CPU Fan Speed : 2008 RPM
System Fan Speed : N/A
CPU Vcore : +0.972 V
DRAM Voltage : +1.608 V
+12V SYS : +11.971 V
+5V SYS : +3.002 V
VBAT : +3.120 V
Smart Fan Function [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enabled Case Open Warning and
open chassis, Intrusion Alarm
will appear. If don’t enter
bios setup and disabled Case
Open Warning one time, Intru
-
sion Alarm don’t clear, it will
appear all the time.
Health
► Case Open Warning
This item is used to enable or disable case open warning function.
► CPU Temperature
These items show the current CPU temperature detected automatically by the system.
► System Temperature
These items show the current System temperature detected automatically by the system.
► CPU Fan Speed
This item shows the current CPU Fan speed detected automatically by the system.
► System Fan Speed
This item shows the current North Bridge Fan speed detected automatically by the system.
► CPU Vcore/DRAM Voltage/+12V SYS/+5V SYS/VBAT
TheseitemsshowtheCurrentCPUCcore/DRAM/+12VSYS/+5VSYS/VBAtvoltagedetected
automatically by the system.
► Smart Fan Function
This option is used to enable or disable smart fan function. Default value is [Disabled].

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
