Exit RAID BIOS
1.TakeTryRAID5asanexample,select“5. Exit” in main menu and press <Enter>.
The screen displays :
2.Press<Y>toexitIntel
®
Matrix Storage Manager program. The system will enter
BIOS setup.
3. Shut down the computer, remove the Non-RAID disk, and we will continue for
Windows OS installation. If you do not remove irrelevant hard disk, Windows may
detect it during the installation, and you could be confused.
4.Removeanydiskettefromoppydrive.
5.RestartcomputertostartWindowsinstallation.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2.DeleteRAIDVolume  4.RecoverVolumeOptions
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID5  RAID5(Parity)64KB 149.1GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1 ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Member Disk(0)
3 ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
5.Exit
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
Are you sure you want to exit? (Y/N):
[ CONFIRM EXIT ]
