Foxconn H61MXV Series User Manual

5
100
4.Press<Space>keytoselectitandpress<Enter>,itreturnstothemainmenu.You
canseethe74.5GBdiskisofine,andactionsofRecoverychangefromContious
Update mode to On-Request.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
  2.DeleteRAIDVolume  5.AccelerationOptions
    5.Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRecovery  Recovery(OnReq)N/A  74.5GB
NeedUpdate Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Recovery Disk(0)
1 ST380811AS 5PS1TAGW 74.5GB Offline Disk(0)
 2 SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Member Disk(0)
3 ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-OptionROM-10.0.0.1032
Copyright(C)2003-10IntelCorporation.AllRightsReserved.
[ DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
4.RecoveryVolumeOptions

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
