Foxconn H61MXV Series User Manual

3
34
Boot
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Boot
Boot Configuration
Bootup Numlock State [On]
Quiet Boot [Enabled]
CSM16 Module Version 07.64
Boot Option Priorities
Boot Option #1 [SATA: WDC WD1600AA...]
Hard Drive BBS Priorities
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select the keyboard NumLock
state
► Bootup Numlock State
ThisitemdenesifthekeyboardNumLockkeyisactivewhenyoursystemisstarted.The
available settings are: On (default) and Off.
► Quiet Boot
This item is used to enable/disable the quiet boot.
[Disabled] : Displays the normal POST messages.
[Enabled] : Displays OEM customer logo instead of POST messages.
► Boot Option Priorities
BIOSautodetectthepresenceofbootdevices,youcancongurethepriorityforbootdevices.
If you connect external devices, the following item will appear:
► Boot Option #1/2/3/...
These items are used to set the system boot order.
► CD/DVD ROM Drive BBS Priorities
This item is used to set the system boot order.of the legacy devices in this group.

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
