Intergrated Clock Chip Conguration
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Integrated Clock Chip Configuration
ICC OverClocking Lib Version 7.0.0.29
Number of ICC Profiles : 1
Current ICC Profile Index : 0
ICC Enable [Enabled]
ICC Set Clock Enables [Enabled]
Send ICC Lock Registers [Enabled]
Set Profile [Enabled]
Set Profile Index 0
▶ ICC OverClocking
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Integrated Clock Chip
Enabled/Disabled.
Chipset
► ICC Enable
This item is used to enable or disable the Integrated Clock Chip(ICC).
► ICC Set Clock Enables
This item is used to enable or disable the ICC clock.
► Send ICC Lock Registers
This item is used to enable or disable send ICC lock registers.
► Set Prole
ThisitemisusedtoenableordisabletheICCprolesupport.
► Set Prole Index
ThisitemappearsonlywhentheSetProleisenabled,itisusedtosetICCproleindex.
► ICC OverClocking
Press <Enter> to go to its submenu. It is used to set ICC clock spread spectrum.
Optionsare:[DIV-1S];[DIV-2S];[DIV3];[DIV4];[DIV-1NS];[DIV-2NS].
