Foxconn H61MXV Series User Manual

5
71
1.FindaPC,putadisketteintoitsoppy
drive A:, this diskette will be formatted later.
Put the driver CD into DVD-ROM drive.
2.Dependingonwhichplatformyoursystem
is,normally,itisa32-bitXPsystem.Use
Windows explorer, and go to CD:\Driver\
Intel\RAID\Floppy\32bit, click on Raid-
Tool icon to start the creation.
3.Click"GO"tostart.
4.SelectthedesireddestinationFDDdrive.
It can be the default drive A: or any USB
FDD.Click"OK"tocontinue.
5.Insertadiskette,click"OK"tocontinue.
5-1 Create a RAID driver diskette
If you want to install a brand new Windows XP on a AHCI or RAID system, you need to
conguretheSATAModeinBIOStoeitherAHCIorRAIDrst.Youalsoneedtocreate
a RAID driver diskette for use in installing your Windows XP system.
Windows Vista has native RAID driver in itself, you can skip these steps.

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
