Foxconn H61MXV Series User Manual

5
68
RAID Conguration Introduction
RAID (Redundant Array of Independent Disks) is a method for computer data storage
schemes that divide and/or replicate data among multiple hard drives. RAID can
be designed to provide increased data reliability (fault tolerance) or increased I/O
(input/output) performance, or both. The motherboard comes with the Intel
®
PCH. The
followingRAIDcongurationsareprovidedforusers.
There are three major key concepts in RAID:
1.Mirroring:Thecopyingofdatatomorethanonedisk;
2.Striping:Thesplittingofdataacrossmorethanonedisk;
3. Error correction : Where redundant data is stored to allow problems to be detected
andpossiblyxed(knownasfaulttolerance).
Different RAID levels use one or more of these techniques, depending on the system
requirements. The main aims of using RAID are to improve reliability, important for
protecting information that is critical to a business, for example a database of customer
orders;orwherespeedisimportant,forexampleasystemthatdeliversvideoon
demand TV programs to many viewers.
Thecongurationaffectsreliabilityandperformanceindifferentways.Theproblem
with using more disks is that it is more likely that one will go wrong, but by using
error checking the total system can be made more reliable by being able to survive
and repair the failure. Basic mirroring can speed up reading data as a system can
read different data from both the disks, but it may be slow for writing if it insists that
bothdisksmustconrmthatthedataiscorrectlywritten.Stripingisoftenusedfor
performance, where it allows sequences of data to be read off multiple disks at the
same time. Error checking typically will slow the system down as data needs to be
read from several places and compared. The design of RAID systems is therefore a
compromise and understanding the requirements of a system is important. Modern
diskarraystypicallyprovidethefacilitytoselecttheappropriateRAIDconguration.
RAID is often used in high availability systems, where it is important that the system
keeps running as much of the time as possible.

Foxconn H61MXV Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
Graphics Interface	PCI Express 3.0 x16
Storage	4 x SATA 3Gb/s
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 on back panel, 4 via headers)
LAN	Realtek RTL8111E Gigabit LAN
Video Outputs	VGA
